WorkFit-C Sit-Stand Workstation

WorkFit-C Sit-stand Workstation is a mobile adjustable desk platform featuring 25'' (63 cm) height adjustment for ergonomic computing in sitting or standing position, allowing you to stay healthy and productive whenever you go. This high mobility computer cart is specifically designed for comfortable long computing by providing easy to access large worksurface, back-tilt keyboard tray, and adjustable monitor stand which are supported with counterbalanced adjustment points to allow handy repositioning during work. As an ideal workspace for various implementation in school, hospital and company, WorkFit-C Sit-stand Workstation accommodates various LCD monitors. It allows you to choose the right model for your needs:

• WorkFit-C, Single LD (Light Duty) Sit-Stand Workstation - for LCDs weighing 6 - 20 lbs and up to 24'' - ideal for office, medical and industrial users.
• WorkFit-C, Single HD (Heavy Duty) Sit-Stand Workstation - for LCDs weighing between 16 - 28 lbs and up to 30'' - ideal for specialty graphics oriented LCDs and 'all-in-one' computers.

* This adjustable computer cart can be configured with additional accessory, Notebook Tray (50-193-200), to hold a laptop instead of a monitor. The accessory can be ordered separately.

Benefits

How Does This Mobile WorkFit-C Sit-Stand Workstation Benefit You?

For Computer Users

Ergonomic Comfort The lightweight WorkFit-C Workstation is equipped with ergonomic features, such as:

• Easy to adjust keyboard and LCD screen for easy lift up and lift down to the most comfortable height
• Telescoping lift engine for height adjustment without blocking the line of sight
• Patented Constant Force™ lift technology for fluid, one-touch adjustments of the keyboard and monitor positions

Better Transportability WorkFit-C Workstation comes with smooth casters for effortless transport through small doorways and over thresholds for collaborative meetings. Improved Fitness This on-demand sit-stand workstation allows for periodic standing on work-day routine to reduce potential back and neck pain, burn more calories, promote greater bone density, and make better sleep at night.

For IT and Facilities Staffs

Effective IT Deployment WorkFit-C Workstation provides fully equipped workstation for temporary workers, thus reducing cost for additional facility and minimizing time used for retrofitting existing stations. When not in use, this compact cart can be easily folded and tucked into corner to save space. Flexible Solutions This adjustable single monitor workstation offers a flexible solution for your facility that allows you to modify existing office spaces or cubes by simply rolling in the sit-to-stand WorkFit, without the need of expensive professional installers. In addition, it also comes with flexible open-architecture design that is scalable for future computer equipment. Durable Material The exterior of WorkFit-C Workstation is constructed with phenolic, high-grade plastic and powder coated painted steel that is highly durable and requires low maintenance. Neat Presentation This lightweight sit-stand workstation comes with expansive Cable Management Box for storage of standard six-outlet power strip, two power bricks, and the associated cables. The safe and neat routing of cables through Cable Management Box presents a neat, clean and professional workstation.

For HR/Risk Management and Company Cost Savings

Smart Investment The adjustable WorkFit-C Workstation offers provable ROI on investment by reducing the cost of healthcare premiums associated with unhealthy computing. It enables you to provide healthy work platforms for your employees without having to buy expensive height-adjustable chairs. This ergonomic platforms help preventing neck and back pain, the most costly conditions affecting employees according to the 2007 OE Medicine Journal. Increased Productivity Studies in office ergonomics show productivity increases 12%–18% as a result of workstyle transformation where employees are provided with furniture that promotes ergonomic comfort**. ** A Washington State analysis of case studies related to office ergonomics present a median productivity increase by 12% following an ergonomic intervention. Other studies from the Office Ergonomics Research Committee (OERC) show that employees who are provided well-designed ergonomic furniture and trained to use it has increased average productivity by 18%.

The Additional Benefit of WorkFit-C, Single LD Sit-Stand Workstation 24-215-085 and WorkFit-C, Single HD Sit-Stand Workstation

Cable Management Box WorkFit-C, Single LD Sit-Stand Workstation 24-215-085 and WorkFit-C, Single HD Sit-Stand Workstation comes with cable management storage box that can be used for storing long cable, adapter, etc.

Specifications

	Screen	Capacity	Lift	Tilt	Pan	Rotation	VESA
WorkFit-C, Single LD Sit-Stand Workstation 24-198-055	≤27''	27 lbs 12.3 kg	25'' 63 cm	25°	-	360°	MIS-D
WorkFit-C, Single LD Sit-Stand Workstation 24-215-085	≤24''	24.9 lbs 11.3 kg	25'' 63 cm	30°	-	360° P/L	MIS-D
WorkFit-C, Single HD Sit-Stand Workstation	≤30''	32.5 lbs 14.7 kg	25'' 63 cm	30°	-	90° P/L	MIS-D



	WorkFit-C, Single LD Sit-Stand Workstation	WorkFit-C, Single LD Sit-Stand Workstation	WorkFit-C, Single HD Sit-Stand Workstation
Part Number	24-198-055	24-215-085	24-216-085
Description	WorkFit-C Sit-Stand Workstation for Single LCD Monitor, LD, with Mobile Cart Base (two-tone grey)	WorkFit-C Sit-Stand Workstation for Single LCD Monitor, LD, with Mobile Cart Base (black/grey)	WorkFit-C Sit-Stand Workstation for Single Large Display, HD, with Mobile Cart Base (black/grey)
Includes	cart, LCD pivot, integrated worksurface, keyboard tray with left/right mouse tray, wrist rest, mouse holder, cable storage box, CPU holder, four dual casters (two locking)	cart, LCD pivot, integrated worksurface, large stowable keyboard tray, cable storage box, CPU holder, four dual casters (two locking), hand-brake system	cart, heavy-duty LCD pivot, integrated worksurface, large stowable keyboard tray, cable storage box, CPU holder, four dual casters (two locking), hand-brake system
Weight Capacity	Maximum load on height-adjustment assembly = 27 lbs (12.3 kg). Includes weight of display in addition to contents on Worksurface and in Cable Storage Box. LCD pivot capacity = 5–18 lbs (2.3–8.1 kg)	Maximum load on height-adjustment assembly = 24.9 lbs (11.3 kg). Includes weight of display and keyboard in addition to contents on Worksurface and in Cable Storage Box. LCD pivot capacity = 6–16 lbs (2.7–7.3 kg)	Maximum load on height-adjustment assembly = 32.5 lbs (14.7 kg). Includes weight of display and keyboard in addition to contents on Worksurface and in Cable Storage Box. LCD pivot capacity = 16–28 lbs (7.3–12.7 kg)
Lift Range	LCD/keyboard/worksurface adjusts 20'' (51 cm) in tandem; LCD adjusts 5'' (13 cm) independently; maximum LCD height adjustment = 25'' (63 cm)
Mounting Standards	VESA FDMI MIS-D, 100/75, C (hole pattern: 100 x 100 mm2& 75 x 75 mm2)	VESA FDMI, MIS-D, 75/100, C (hole pattern = 100 x 100 mm2& 75 x 75 mm2). For displays that use a 200 x 100 mm2, 200 x 200 mm2, 400 x 200 mm2, 400 x 300 mm2 or 400 x 400 mm2 hole pattern, the VESA Bracket Adaptor Kit (97-759) can be ordered separately
Compatibility	CPUs from 12''H x 3''D to 18''H x 8.5''D (30 x 8 cm2 to 46 x 22 cm2) (attach safely to rear of cart with CPU Holder)	CPUs from 9.4''H x 2.6''D to 15.75''H x 8.5''D (24 x 6.5 cm2 to 40 x 22 cm2) (attach safely to rear of cart with CPU Holder)
CPU Holder Capacity	40 lbs (18 kg)
Keyboard Tray	Available. Ergonomic negative-tilt keyboard tray ensures wrists remain in a neutral position during data entry—avoid repetitive-stress injuries while increasing comfort and productivity.	26.3'' x 9.4'' (67 x 24 cm2). Stowable under worksurface. Includes 5° back-tilt to ensure wrists remain in a neutral position during data entry
Mouse Tray	Includes concealed mouse tray that slides out on left or right	-	-
Worksurface Dimensions	22''W x 17''D (56 x 43 cm2)	24''W x 23''D (61 x 58 cm2)
InteriorDimensions of Cable Management Box	-	13.4''W x 5.1''D x 3.4''H (34.1 x 12.8 x 8.6 cm3)
Keyboard Heights	From ground: Minimum, 22.4'' (568 mm); Maximum, 42.4'' (1077 mm)	From ground: Minimum 25.4'' ( 64.516mm); Maximum 45.4'' (115.316mm)
Display Heights (Center of Hole Mounts for Display)	From ground: Minimum, 34.8'' (884 mm); Maximum, 59.8'' (1519 mm)	From ground: Minimum 39.4'' ( 100.076); Maximum 64.4'' ( 163.576)
Casters	Four (4) dual casters— two (2) lockable front casters
Wheel-to-wheel BaseDimensions	17''W x 20.5''D (43 x 52 cm)	25''W x 22''D (63.5 x 56 cm2)
Shipping Dimensions	45.5''H x 19.75''W x 24''D (116 x 50 x 61 cm)	36.5'' x 32.25'' x 28.25'' (93 x 82 x 72 cm3)
Shipping Weight	72 lbs (33 kg)	91 lbs (41.3 kg)
Warranty	Five (5) years
